1. Tailored for different industries, reasonable structure, elegant, and practical.

2. High-precision mold casting profiles composed of high-strength, high mechanical stability of the structure,  CNC smooth motion, high speed

and high precision, long-term operation without adjustment,carving precision unchanged. Around the body through the design, you can easily back and forth through the

material for infinite workpiece.

3. Stable and perfect design, equipped with advanced industrial cooling system with water alarm

automatic protection function, improve the stability, security of continuous work. Perfect dust,

pollution prevention design, greatly improving the overall stability.

Processing area

Laser type

Co2 glass laser tube

Software

RDworks

Engraving speed

1000mm/s

Cutting speed

500mm/s

Cutting thickness

determined by materials

Position system

Red dot

Interface

USB

Resolution Accuracy

±0.1mm

Support graphic format

DST, PLT, BMP, DXF

Gross power

1000W

Cooling mode

Circulation water cooling

Working voltage

AC220V/50HZ or 110V/60HZ or depend on customer

Option

Rotary attachment for column materials

Operation

Video to tell customer how to operate the machine

1.Professional Laser head with

red light pointer and auto focus

The laser is invisible. Red dot shows

the position of the laser on the material.

It’s more convenient for location.

Auto focusing automatically adjust

the focusing distance.

2.Ruida 6442s control system( You can see

the cutting path from the control panel)

USB offline,English version,very easy

to learn and operate.

There has Independent control

switch for exhaust fan.

3. Laser Tube ( Original Reci laser tube , Best band in china )

Using life :8000-10000 hours

Global Warranty 10 months

4. Motor : Stepper motor

High-power motor , high speed, low noise,

smooth running,big cutting torque

5. Control cabinet

Includes control board , drive, transformer (switching power supply), filter,leakage protector, control card, wire etc .

6.Laser supplier mached with the laser tube

Laser power supplier installed Independent , compared with the general install together with other Electrical Equipment,  it can Reduce interference of other

Electrical Equipment this can ensure the better performance of the laser power.

7. Table : Blade table or Honeycomb table

Blade table : mainly aimed at the material such as acrylic , mdf , plywood etc , blade table is usually relatively thick, can afford to compare heavy plate material.For example, 20MM thick acrylic is very heavy.

Honeycomb table is aimed at soft thin material such as leather, clothing,fabric . because when fabric on top may be uneven, honeycomb in convulsions may have the effect of the suction flat on the table cloth, guarantee the effect of the machine.

8. UP/Down working table ( If your material thickness more than 25mm , you need add this, it can up to 300mm)

Applicable Material laser fiber marking machine
It is capable of carving the metal materials and partial non-metal materials,
especially suitable for some fields required more precise and higher smoothness.
It is widely used in the electronics separation components,integrated circuit.
Metal,alloy ,oxide,ABS,epoxy resin,printing ink,etc. which are widely applying for electronics,jewelry,automobiles,communication products,plastic buttons,IC,etc.

Applicable Industry laser fiber marking machine:
electrical engineering circuit,mobile communication,hardware,tools,kitchen wares,tool fittings,precise apparatus,eyeglasses and cloc,computer keyboard,jewelry accessories,plastic buttons,water heating fittings,sanitary ware,PVC pipelines,medical apparatus and packing container,etc.
Electronics, medicine, tobacco, leather, packaging, beverages, food and other industries, for the production date, batch number, bar code on the line in the high-performance automated laser marking.
