SURFLO BWDS-4000A quietly working DC 12V electric water dispenser mini pump 1GPM 40PSI automatic switch CE approval | Обустройство

SURFLO BWDS-4000A quietly working DC 12V electric water dispenser mini water pump 1GPM 40PSI automatic switch

Instruction:

SURFLO BWDS-4000 series Bottled Water Dispensing System was designed to pump purified water from a commercially available 5-gallon purified water bottle. The system will deliver the water under pressure to an individual drinking water faucet, the water inlet of a refrigerator for the ice-maker and chilled drinking water tap, and to certain commercial coffee / tea brewers.

When the suction wand is inserted into the standard 5-gallon bottle, it will activate the float switch on the end of the wand and turn on the pump. This same float switch shuts off the system when the bottle is empty. The wand has a built in back-flow preventer valve that prevents water in the system from flowing back into the bottle, or spilling while changing bottles.
The heart of the system is the pump module that automatically adjusts the flow and pressure to fill an appliance or faucet, and stops automatically.

The system is equipped with an automatic thermal cut-off device for additional protection.Float switch for automatic shut-off when bottle is empty.

Application:

Liquid bottle dispenser is ideal for mobile locations or home users who can't or don't want to direct plumb. The Bottled Water Dispensing System will deliver the water under pressure to an individual drinking water faucet, the water inlet of a refrigerator for the ice-maker and chilled drinking water tap, and to certain commercial coffee / tea brewers.

Pump included:

•Suction wand and hose assembly.
•Pump module with On/Off switch.
•6 foot cord with plug.
•20 feet of 1/4" discharge tube
•Universal seal cap: Fits any 3, 5, and 6 gallon plastic water bottle.
•Installation and maintenance instructions.

Feature:
1.Easiest way to connect this to your filtration kit/espresso machine
2.Float switch for auto shut-off when bottle is empty
3.Built-in check valve to prevent back flow
4.Universal seal cap fits most water containers
5. Compact size for easy mounting
6.Long Life Motor: Ensures years of reliable operation
7.Easy installed

Specifications:
   Max. Flow Rate: 1.0 gpm (3.8 lpm)
   Max. Pressure: 40 psi (2.8 bar)
   Dimensions: 3.0 H x 5.5 W x 7.5 D inches (7.6 x 14.0 x 19.0 cm)
   Voltage 115 or 230 V AC 12 V DC
   Amp Draw: 12 Volt 3.0 Amps. Max.
   115 Volt   0.5 Amps. Max.
   230 Volt   0.25 Amps. Max.
   Cycles: AC models 50/60 Hz
   Weight: 2.9 kg(5.6 net lbs)

Note: DC 12V as default in the page. Please contact us for special requirement.

Use Instructions

Thanks for purchasing our product.

1. Before starting the pump, please make sure connecting the pump to DC/AC power with 12V/110V/220V.

2. Check if the input voltage are in the right way fitted to + and - of the motor.

3. No solid particles is allowed in the liquid.

4. Please operate the pump periodically in case of the motor over heating.

5. Avoid running dry for a long time.

If any problem you meet during using, please contact us for help or consult.
